Massey Ferguson 260 is a capable tractor to have. It has an engine with a 60 horsepower capacity. Massey Ferguson 260 consists of a turbocharged engine which is extremely powerful. It is highly fuel efficient which is one of its main features. Less smoke is emitted by it due to better burning of fuel. Massey Ferguson 260 has a manual steering drive in it. It is available with us at a very reasonable price range and gives an impressive performance. It has a fuel capacity of 47.5 liters and a spring suspension deluxe seat. For our dear farmers of UAE, we have Massey Ferguson 260 2WD for sale at unbelievable prices.
| Engine Power at 2,250 rpm> | 60 (B.S) hp |
| Torque at 1,600 rpm | 212 Nm |
| PTO Power at Rated | 48hp |
| Engine Speed | |
| *Certified at BS AU 141a 1971 | **Manufacturer’s Estimate |
| Voltage | 12V, Negative Earth |
| Battery | 110 Ah |
| Starter | 2.2 kW |
| Alternator | 32 Amp |
| Type | Sliding Spur |
| Number of Gears | 8 Forward, 2 Reverse |
| Road Speed at 2,250 | Engine RPM with 14.9/13-28 rear tyres |
| Gear | Speed (km/hr) |
| Forward 1 (First Low) | 2.7 |
| Forward 2 | 3.9 |
| Forward 3 | 5.3 |
| Forward 4 | 7.2 |
| Forward 5 (First High) | 10.6 |
| Forward 6 | 15.6 |
| Forward 7 | 21.3 |
| Forward 8 | 28.7 |
| Reverse 1 (Low) | 3.6 |
| Reverse 2 (High) | 14.5 |
| Functions | Draft Control, Position Control Response Control, Constant Pumping |
| Pump Type | Reciprocating, Ferguson Pump |
| Oil Flow | 16 ltr/mix |
| Pressure | 21.0 Mpa at normal operating temperature |
| Links Horizontal | |
| Lower Links | With Cat, I & II Interchangeable Balls |
| Brake Type | Oil immersed, Multi-disc |
| Brake Actuation | Mechanical |
| Axle Type | Straddle with apicyclic redution |
| Parking Brake | Hand Lever Operated |
| Front | 7.50 - 16 (6PR) |
| Rear | 14.9 / 13 - 28 (6PR) |
| Type | Dual |
| Diameter | 305 x 254 mm |
| Type | Box Section, Adjustable |
| Type | Manual |
| Front Axle | 1,245 - 1,854 mm |
| Rear Axle | 1,423 - 2,134 mm |
| Make / Type | Diesel T 3.1524 |
| No. of Cylinders | 3 |
| Rear Axle | 1,423 - 2,134 mm |
| Make / Type | Diesel T 3.1524 |
| No. of Cylinders | 3 |
| Injection | Direct |
| Bore | 91.4mm |
| Stroke | 127.0mm |
| Capacity (litres) | 2.5 L |
| Compression Ratio | 15.5:1 |
| Aspiration | Turbo |
| Starting Aid | Thermostart |
| Throttle Control | Hand and Feet |
| Cooling | Water |
| Air Cleaner Type | Oil Bath |
| Air Pre-Cleaner | Over Bonnet, Air Swirl |
| Fuel Filter | Dual, High Capacity |
| Exhaust | Vertical |
| Oil Cooler | Air Cooler, Fin Type |
| Type | Live |
| Engine Speed at 540 pto rpm | 1,789 rpm |
| Shaft Diameter | 35mm |
| No. of Splines | 6 |
| Guages | Technometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature |
| Warning Lights | Direction Indicators, Battery Charge, Headlight Main Beam, Low Engine Oil Pressure & Brake Lights |
| Gross Weight | 1,900 kg |
| Wheel Base | 1,892 mm |
| Overall Length | 3,260 mm |
| Overall Width (Min) | 1,890 mm |
| Over Exhaust | 2,220 mm |
| Over Steering Wheel | 1,490 mm |
| With Brakes | 5,840 mm |
| Without Brakes | 6,580 mm |
| Under Gear Box | 400 mm |
| Fuel Tank | 47.0L |
| Engine Pump | 6.8L |
| Cooling System | 10.2L |
| Hydraulic System | 36.0L |
| Steering Box | 0.9L |
| Oil Bath Air-Cleaner | 0.5L |
