Massey Ferguson MF 360 Tractor In UAE is a powerful model of Massey Ferguson which comes with hydrostatic power steering. This model is efficient, powerful, and easy to operate. Its longer wheelbase provides greater pulling power. Massey Ferguson 360 2WD has a high-performance engine installed in it. One of the main features that make it distinct is that it has a powerful engine with considerably less fuel consumption. Massey Ferguson 360 has a fuel tank of 45 liters capacity. With a stroke of 127 mm and 2.5 cylinders injection in the engine, it is a very popular option that we have for sale.
| Engine Power at 2,250 rpm> | 60 (B.S) hp |
| Torque at 1,350 rpm | 212 Nm |
| PTO Power at Rated | 48 hp |
| Engine Speed | |
| *Certified at BS AU 141a |
| Voltage | 12V, Negative Earth |
| Battery | 118 Ah |
| Starter | 2.2 kW |
| Alternator | 32 Amp |
| Type | Sliding Spur |
| Number of Gears | 8 Forward, 2 Reverse |
| Road Speed at 2,250 | Engine RPM with 14.9/13x28 rear tyres |
| Gear | Speed (km/hr) |
| Forward 1 (First Low) | 2.6 |
| Forward 2 | 3.8 |
| Forward 3 | 5.2 |
| Forward 4 | 7.0 |
| Forward 5 (First High) | 10.4 |
| Forward 6 | 15.2 |
| Forward 7 | 20.8 |
| Forward 8 | 28.0 |
| Reverse 1 (Low) | 3.5 |
| Reverse 2 (High) | 14.1 |
| Functions | Draft Control, Position Control Response Control, Constant Pumping |
| Pump Type | Reciprocating, Ferguson Pump |
| Oil Flow | 16.0 ltr/min |
| Pressure | 21 Mpa at normal operating temperature |
| Lift Capacity with Lower | 2,145 kg |
| Links Horizontal | |
| Lower Links | With Cat. I & II Interchangeable Balls |
| Axle Type | Straddle with apicyclic redution unit |
| Brake Type | Oil immersed, Multi-disc |
| Brake Pedal | Pendant |
| Differential Lock | Mechanical |
| Brake Actuation | Mechanical |
| Parking Brake | Hand Lever Operated |
| Front | 7.50 - 16 (6PR) |
| Rear | 14.9 / 13 - 28 (6PR) |
| Type | Dual |
| Diameter | 305 x 254 mm |
| Type | Box Section, Adjustable |
| Type | Hydrostatic |
| Front Axle | 1,275 -1, 884 mm |
| Rear Axle | 1,438 -2, 124 mm |
| Make / Type | Diesel /T 3.1524 |
| No. of Cylinders | 3 |
| Injection | Direct |
| Bore | 91.4mm |
| Stroke | 127.0mm |
| Capacity (litres) | 2.5L |
| Compression Ratio | 16.5:1 |
| Starting Aid | Thermostart |
| Throttle Control | Hand and Feet |
| Cooling | Water |
| Air Cleaner Type | Oil Bath |
| Air Pre-Cleaner | Over Bonnet, Air Swirl |
| Fuel Filter | Dual, High Capacity |
| Exhaust | Vertical Muffler under bonnet |
| Oil Cooler | Water Cooled |
| Type | Live |
| Engine Speed at 540 pto rpm | 1,789 rpm |
| Shaft Diameter | 35mm |
| No. of Splines | 6 |
| Guages | Technometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature |
| Warning Lights | Direction Indicators, Battery Charge, Headlight Main Beam, Low Engine Oil Pressure, Brake Lights & Auxiliary Socket |
| Gross Weight | 2,010 kg |
| Wheel Base | 2,032 mm |
| Overall Length | 3,353 mm |
| Overall Width (Min) | 1,890 mm |
| Over Exhaust | 2,236 mm |
| Over Steering Wheel | 1,499 mm |
| With Brakes | 5,876 mm |
| Without Brakes | 6,833 mm |
| Under Gear Box | 400 mm |
| Fuel Tank | 47.5 L |
| Engine Pump | 6.8 L |
| Cooling System | 11.7L |
| Hydraulic System | 36.0L |
| Steering Box | 2.0L |
| Oil Bath Air-Cleaner | 0.5 L |
